MODULES

Modular technology

Kufferath modules form the interface between the test piece and the testing setup. They are available individually and can be integrated not only into Kufferath test benches but also into existing systems from other manufacturers.

Flexible, adaptable, and tailored to your needs - providing the building blocks for precise and efficient testing across a wide range of applications.

TESTCASE COVERAGE

Modules are designed to inspect components according to precise test criteria, covering electrical, mechanical, functional, and visual inspection requirements:

• Function, seating, and interlocking checks
• Assembly and connector verification
• Leak, pressure, and vacuum testing
• Continuity and defect detection
• Pull tests and visual inspection

We also custom-engineer special modules for your use case, ensuring tailored solutions for even the most demanding testing requirements.

UPGRADE OPTIONS

Mechanical modules can be enhanced with pneumatic and moving-block components to improve test quality and process stability. These mechanisms reduce insertion forces, improve locking conditions and minimize operator influence. Upgrades are available for most test cases and are applied where increased reliability is required.

While upgrades are often chosen to achieve higher performance and process robustness, they can also be a technical requirement. Certain test cases, such as pressure tests, mandate the use of pneumatic mechanisms.

Macro Module Configurations

For complex test cases or specific customer requirements, multiple modules can be combined into one macro module. This integrated approach ensures all mechanical, electrical, and functional checks are performed in a single, streamlined process.

Key Benefits:

• Custom combinations of standard and special modules
• Optimized workflows for multi-step or high-complexity tests
• Scalable design for future adaptations
• Compatible with Kufferath and third-party systems

Ideal when individual modules alone cannot meet the full scope of testing requirements.

DIMENSIONS

Our modules are available in standard sizes:

• 50 × 50 mm
• 50 × 100 mm
• 100 × 100 mm

Custom formats can also be supplied to fit specific requirements, making our modules suitable for integration into both Kufferath test systems and third-party test benches.

RESULTS & RELIABILITY

After a successful test, the test piece is released either automatically or via manual confirmation. Test results are issued as a printout, for example as a label, and are stored for documentation purposes. This ensures traceable, consistent and reproducible documentation of all test results over the entire product lifecycle.

Key characteristics:

• Traceable test results documented and stored for quality assurance
• Reliable release mechanisms automatic or manual confirmation after successful testing
• High durability designed for a high number of test cycles
• Low wear optimized for repeated insertion and removal of test plugs
• Operator-friendly handling robust design with intuitive operation

DECISION SUPPORT & CONSULTING

Selecting the right module configuration is essential for reliable and stable test results. Depending on the application, requirements may range from simple mechanical validation to more advanced test concepts with pneumatic or sensor-based components.

Our consulting approach helps to:

• Define the right test depth based on the actual test objective
• Avoid overengineering that may cause false positives or unstable processes
• Select the appropriate modules and upgrades for performance, reliability and cost
• Achieve the fastest and most economical solution for your application

If you are unsure which module configuration is best suited for your test case, our experts support you throughout the decision process.

Visual Impressions

Take a closer look at a few more examples and see the precise fit, clean engineering, and consistent high-quality craftsmanship Kufferath delivers across a wide range of real test cases.

Each module is thoughtfully designed for reliable, repeatable performance. Browse through these examples to get a better sense of the attention to detail and versatility our solutions offer.
